Heat Pumps and Furnaces
Heat Pumps
The OTP-F Flexx Series offers air conditioning, heating, ventilation, dehumidification and automatic modes. With rated capacities from 24,000 to 60,000 BTU/h, it offers exceptional efficiency (up to 20 SEER and 10.5 HSPF). Suitable for homes, offices, commercial buildings and restaurants.
Main Features
- Indoor Unit:
- Blower Cabinet: Compact and Compatible with Most Standard 24V Thermostats
- Cased Coil: Horizontal or Vertical Installation
- Outdoor Unit:
- Variable-Speed Rotary Compressor (INVERTER)
- More Resistant to Corrosion (Hydrophilic Condenser Fins)
- Quiet Axial Fan
- Anti-Freeze Technology and Integrated Preheating
- Piping: Min. Length 7.5 m, Flared Connections
- Performance :
- Up to 20 SEER (Cooling), 10.5 HSPF (Heating)
- Cooling Operation: -15 to 54°C
- Heating Operation: -30 to 24°C
- Comprehensive Protection, Self-Diagnosis, Energy Savings
- Warranty: 10 Years (Parts and Compressor), Option for Labour up to 10 Years
- FXD-ACD36 (24000 BTU)
- Up to 20 SEER and 10.5 HSPF
- R410A Refrigerant Volume of 9,3 lb
- FXD-ACD36 (36000 BTU)
- Up to 18 SEER and 10 HSPF
- R410A Refrigerant Volume of 9,3 lb
- FXD-ACD60 (48000 BTU)
- Up to 18 SEER and 10.5 HSPF
- R410A Refrigerant Volume of 12,3 lb
- FXD-ACD60 (54000 BTU)
- Up to 17 SEER and 10 HSPF
- R410A Refrigerant Volume of 12,3 lb
Furnaces
Keeprite G96VTN QuietComfort® 96 Gas Furnace
Stay warm when it's cold outside with your high efficiency gas furnace. Its reliable two-stage operation and variable speed blower provide better temperature control for your comfort.
The fan also allows you to enjoy better dehumidification in the summer, as your furnace works with your cooling unit to help pull moisture out of the air.
Features and Benefits
• Variable speed blower motor and two-stage gas valve provide increased levels of temperature control and comfort.
• Bi-Fuel capability with compatible heat pump and thermostat for energy efficient heating.
• Fully insulated cabinet keeps heat from moving to your ducts.
• Compatible with air cleaners and humidifiers
• High temperature limit control prevents overheating
• 5-year limited "No Hassle Replacement™"* warranty
• 10-year limited warranty on parts after timely registration.
• Limited lifetime warranty on heat exchanger after timely registration.
Specifications
• Variable speed, constant torque ECM blower motor
• Variable speed induced draft combustion engine
• Energy saving two-stage gas valve
• RPJ® (Rigid Press Joint) primary heat exchanger, stainless steel secondary heat exchanger
• Pre-painted solid steel insulated cabinet with tight-fitting door lock system
• Soundproofing features: smoothly mounted fan and induction motor.
• Heating capacity: 60,000-120,000 BTUh
Electric Furnace
Dettson's Supreme Series
offers unrivalled comfort thanks to its modular design, quiet operation, and optimum energy efficiency. Compatible with PSC or ECM motors, it offers various options to suit your needs. Simple, multi-position installation, perfect for traditional or mobile homes.
PSC Motor
General Features
- 3-4-Speed Direct Drive
- 2-Wire (208/240V) and 3-Wire (120-208/240V) Models
- Sequential and Silent Operation of Electrical Elements
- Approved Connection for Copper or Aluminum Wires
- Zero Clearance for Installation in Mobile Homes
- Separately Framed Elements for Quick and Easy Replacement
- Optimized Air Supply Duct (20“ x 20”)
Comfort Series
- Galvanized Steel Cabinet
- Internal Circuit Breakers
- Entry-Level Option
Advantage Series
- Painted Steel Cabinet
- Accessible Front-Mounted Circuit Breakers
- Continuous Ventilation Switch on Front Panel for Convenient Control
- Front Panel Low/High Power Selector
- LED Indicator for Heating Demand
ECM Motor
General Features
- Variable-Speed ECM Motor
- 2-Wire (208/240V) and 3-Wire (120-208/240V) Models
- Sequential and Silent Operation of Electrical Elements
- Approved Connection for Copper or Aluminum Wires
- Zero Clearance for Installation in Mobile Homes
- Separately Framed Elements for Quick and Easy Replacement
- Optimized Air Supply Duct (20“ x 20”)
- Painted Steel Cabinet
- Front-Mounted Circuit Breakers
Advantage Series
- Continuous Ventilation Selector Switch in Front Panel for Convenient Control
- Front-Mounted Low/High Power Selector for Flexible Power Management
- LED Indicator for heating Demand, Allowing Easy Monitoring
Modulating Series
- 0-100% Semi-Conductor Modulation for Exceptional Comfort and Ultra-Quiet Operation
- Control Board for Total Control and Easy Configuration
- Compatible with the Smart Duct System®
Keep a Zen and Warm Atmosphere in your Home with an Efficient Furnace or Heat Pump!
